Digital PLC Module Functional 6ES7136-6RA00-0BF0 F-RQ 1X24VDC/24..230VAC/5A ST
| Place of Origin | Germany |
|---|---|
| Brand Name | Siemens |
| Certification | CE |
| Model Number | 6ES7136-6RA00-0BF0 |
| Minimum Order Quantity | 1 unit |
| Price | ＄126 negotiable |
| Packaging Details | 6.80 x 8.00 x 2.90CM |
| Supply Ability | 100 unit |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Place Of Delivery | China | Net Weight (Kg) | 0.070 Kg |
|---|---|---|---|
| Package Size | 6.80 X 8.00 X 2.90 | Packaging Size Unit | CM |
| Product Family | Digital Quantity F Output Module Relay | Product Type Mark | F-RQ 24 ... 48VDC/24 ... 230VAC/5A ST |
| Available Basic Units | F0 Base Unit | Rated Value (DC) | 24 V; Coil Voltage |
| High Light | Digital PLC Module,PLC Module Functional,6ES7136-6RA00-0BF0 |
||
Product Description
Siemens Plc 6ES7136-6RA00-0BF0 ET200SP, F-RQ 1X24VDC/24..230VAC/5A ST PLC Module
SIMATIC DP, electronic module for ET200SP, F-RQ 1x 24VDC/24.230VAC/5A ST, 20mm structure width, 1 relay output terminal (2NO) total output terminal current 5A, load voltage 24V DC and 24.230V AC, can be used to PL E (ISO 13849-1:2008)/SIL 3 (IEC 61508:2010) when control is carried out through functional digital outputs (such as 6ES7136-6DB00-0CA0)
| STEP 7 TIA port, configurable/integrated, self version | V13 |
| STEP 7 configurable/integrated, self version | V5.5 SP4 or above |
| PROFINET version GSD version/above GSD revision | V2.31 |
| DC | 24V |
| Allowable range, lower limit (DC) | 20.4 V |
| Allowable range, upper limit (DC) | 28.8 V |
| Power output from backplane bus | 100 mW |
| Power loss, typical value | 1 W |
| Types of mechanical encoding keys | Type C |
