6AV6647-0AB11-3AX0 Siemens KTP600 Basic Mono PN HMI Touch Panel Button/Touch Operation
| Place of Origin | China |
|---|---|
| Brand Name | Siemens |
| Certification | CE |
| Model Number | 6AV6647-0AB11-3AX0 |
| Minimum Order Quantity | 1 unit |
| Price | ¥4500 |
| Packaging Details | Original packaging |
| Supply Ability | 70 unit |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Weight (excluding Packaging) | 1.07 Kg | Weight (including Packaging) | 1.3 Kg |
|---|---|---|---|
| Front Width Of Shell | 214 Mm | Shell Front Height | 158 Mm |
| Installation Section, Width | 197mm | Installation Section, Height | 141 Mm |
| Installation Depth | 44 Mm | Shell Material (front) | Plastics |
| High Light | 6AV6647-0AB11-3AX0 HMI Touch Panel,Siemens KTP600 HMI Touch Panel,Basic Mono PN HMI Touch Panel |
||
Product Description
6AV6647-0AB11-3AX0 Siemens KTP600 Basic Mono PN HMI Touch Panel Button/Touch Operation
| Protection level and protection category | Front IP65 |
| Available memory for user data | 1 Mbyte |
| Processor type | RISC 32-bit |
| Typical value of effective power received | 6W |
| Current consumption (rated value) | 0.24 A |
| Connect current pulse I ² T | 0.5 A²·s |
| The voltage type of the power supply | DC |
| Rated value (DC) | 24 V |
| Allowable range, lower limit (DC) | 19.2 V |
| Allowable range, upper limit (DC) | 28.8 V |
| Installation position | vertical |
| Touch screen specifications | Analog resistor |
