Mobile PLC HMI Panel Intelligent Screen 6AV2125-2JB23-0AX0 KTP900F
| Place of Origin | Germany |
|---|---|
| Brand Name | Siemens |
| Certification | CE |
| Model Number | 6AV2125-2JB23-0AX0 |
| Minimum Order Quantity | 1 unit |
| Price | ＄3280 negotiable |
| Packaging Details | 24.50 x 32.10 x 10.30CM |
| Supply Ability | 80 unit |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Place Of Delivery | China | Net Weight (Kg) | 1.766 Kg |
|---|---|---|---|
| Package Size | 24.50 X 32.10 X 10.30 | Packaging Size Unit | CM |
| Product Type Mark | KTP900F Mobile | Display Screen Specifications | TFT Widescreen Display With LED Backlight |
| Number Of Colors | 16 777 216 | Screen Diagonal | 9 In |
| High Light | Mobile PLC HMI Panel,PLC HMI Panel Intelligent,6AV2125-2JB23-0AX0 |
||
Product Description
PLC HMI Panel 6AV2125-2JB23-0AX0 KTP900F Mobile Siemens Intelligent Panel
SIMATIC HMI KTP900F Mobile, 9.0 "TFT display screen, 800x 480 pixels, 16m color, button and touch operation, 10 function keys, 1 PROFINET/Industrial Ethernet interface, 1 multimedia card, 1x USB, key switch, confirm button, emergency stop button, minimum version WinCC Smart 13 SP1 with project configuration
| Voltage type of power supply | DC |
| Rated value (DC) | 24 V |
| Allowable range, lower limit (DC) | 19.2 V |
| Allowable range, upper limit (DC) | 28.8 V |
| Current consumption (rated value) | 450 mA |
| Typical value of effective power received | 11 W |
| Available storage for user data | 12 Mbyte |
| Environmental temperature during operation | 0 °C-45 °C |
