PLC 6AV2124-0QC02-0AX1 Smart HMI TP1500 Comfort Panel Touch Screen
| Place of Origin | Germany |
|---|---|
| Brand Name | Siemens |
| Certification | CE |
| Model Number | 6AV2124-0QC02-0AX1 |
| Minimum Order Quantity | 1 unit |
| Price | ＄5778 negotiable |
| Packaging Details | 44.50 x 60.00 x 17.50CM |
| Supply Ability | 80 unit |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Place Of Delivery | China | Package Size | 44.50 X 60.00 X 17.50 |
|---|---|---|---|
| Packaging Size Unit | CM | Net Weight (Kg) | 5.580 Kg |
| Voltage Type Of Power Supply | DC | Rated Value (DC) | 24 V |
| Allowable Range, Lower Limit (DC) | 19.2 V | Allowable Range, Upper Limit (DC) | 28.8 V |
| Highlight | Smart HMI TP1500,HMI TP1500,TP1500 Comfort Panel |
||
Product Description
6AV2124-0QC02-0AX1 PLC HMI Panel TP1500 Siemens Smart Touch Screen Panel
SIMATIC HMI TP1500 smart, smart panel, touch operation, 15 "wide screen TFT (color) display screen, 16 million colors, PROFINET interface, MPI/PROFIBUS-DP interface, 24MByte project configuration memory, WEC 2013, configurable minimum version WinCC Comfort V14 SP1 with HSP, ambient temperature up to 50 ° C (maximum 55 ° C (limited))
| Current consumption (rated value) | 1.7 A |
| Typical value of effective power received | 41 W |
| Processor type | X86 |
| Available storage for user data | 24 Mbyte |
| Environmental temperature during operation | 0 °C-50 °C |
| Environmental temperature during transportation/storage | -20 °C-60 °C |
| HMI MM memory card: multimedia memory card | 128 MB |
| HMI SD memory card: digital memory card | 2 GB |
| SIMATIC IPC USB flash memory (USB memory stick) | 16 GB |
| SIMATIC HMI USB memory (USB memory stick) | 8 GB |
