OP73micro HMI Touch Panel ARMProcessor 6AV6640-0BA11-0AX0 0.1 A
| Place of Origin | Germany |
|---|---|
| Brand Name | Siemens |
| Certification | CE |
| Model Number | 6AV6640-0BA11-0AX0 |
| Minimum Order Quantity | 1 unit |
| Price | ＄322 negotiable |
| Packaging Details | 9.30 x 18.10 x 5.60CM |
| Supply Ability | 20 unit |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Place Of Delivery | China | Net Weight (Kg) | 0.291 Kg |
|---|---|---|---|
| Package Size | 9.30 X 18.10 X 5.60 | Packaging Size Unit | CM |
| Product Type Mark | OP 73micro | Display Screen Specifications | STN |
| Horizontal Image Resolution | 160 Pixel | Vertical Image Resolution | 48 Pixel |
| High Light | OP73micro HMI Touch Panel,HMI Touch Panel ARM,6AV6640-0BA11-0AX0 |
||
Product Description
6AV6640-0BA11-0AX0 HMI Touch Panel Operator Panel OP73micro Siemens Touch Screen
SIMATIC Operator Panel OP 73micro, used for SIMATIC S7-200 3 LC display screens, supports graphics, and can be configured with backlight. The minimum version of WinCC flexible 2004 Micro HSP includes open source software, with free transfer of heating. See attached CD
| Installation position | vertical |
| Maximum allowable tilt angle without external ventilation | 80° |
| Voltage type of power supply | DC |
| Current consumption (rated value) | 0.1 A |
| Processor type | ARM |
| Available storage for user data | 128 kbyte |
| Interface/Bus Type | 1x RS 485 (maximum 187.5 kbit/s) |
| qualification | CE, GL, ABS, BV, DNV, LRS, UL, CSA, cULus, C-TICK, NEMA 4x |
| Operation, maximum value | 90 % |
